T-RCZZ3 — Typ. Reveal @ Opening Detail

Telecommunications · T-RCZZ3

Typ. Reveal @ Opening Detail

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: T4.1
Discipline: Telecommunications

Materials

Concrete Reinforced Concrete

In this detail

3/4" 3/4" DIMENSION LINE ON TILT TICKETS REVEAL TILT PANEL (PER TILT DRAWINGS) OPENING PER TILT TICKETS OPENING INTERIOR FACE EXTERIOR FACE CHAMFER PER ARCH. AS REQ'D DIMENSION LINE ON TILT TICKETS
