Structural · S-VHX7M

Footing Detail

Units: imperial
Sheet: SD2
Discipline: Structural

Materials

Concrete Reinforced Concrete Steel

In this detail

CONC RAMP/ LANDING PAD SEE PLAN CONC SLAB ON GRADE SEE PLAN 3/4"Øx2'-0" LONG SMOOTH DOWELS @ 18"OC (BELOW ANGLE) (2) MIN 6 FOOTING DETAIL N.T.S. - "W" SEE FDN PLAN
