S-TTGWJ — Typical Transverse And Longitudinal Bracing

Structural · S-TTGWJ

Typical Transverse And Longitudinal Bracing

Scale: 1" = 1'-0"
Units: imperial
Sheet: S-63001
Discipline: Structural

Materials

In this detail

TRAPEZE, SEISMIC BRACING LADDER TRAY MAX. 45.00° UNISTRUT P1843W HINGE UNISTRUT P1000 CHANNEL TRAPEZE SUPPORT UNISTRUT P1000 CHANNEL BRACE STIFFEN ROD PER DETAIL THREADED ROD, SEE DETAIL 4/S790 90.00° ± 7.5 DEG. UNISTRUT P1000 CHANNEL BRACE UNISTRUT ?? HINGE OVERHEAD VIEW SECTION VIEW NOTE: SEE EQUIPMENT BRACING NOTES ON THIS SHEET FOR SPACING OF TRANSVERSE AND LONGITUDINAL BRACING 1/S-63001 3/S-63001

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
