S-TQRVY — Wide Flange Drag Strut At Column

Structural · S-TQRVY

Wide Flange Drag Strut At Column

Scale: 1" = 1'-0"
Units: imperial
Sheet: S-62002
Discipline: Structural

Materials

Metal (misc.)Steel

In this detail

WIDE FLANGE BEAM RE: PLAN T. O. SLAB RE: PLAN WIDE FLANGE BEAM RE: PLAN SLAB ON METAL DECK RE: PLAN PL A572 GR50 WITH A325N BOLTS 3/8 3/8 3 SIDES, TYP NOTE: AT SIM SECTION, THERE IS A BRACED FRAME ON ONE SIDE OF COLUMN. RE: S-62201 FOR BRACED FRAME DETAILING TYP 1 1/2" TYP 3" 0'-0 1/2"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
