S-SVR25 — Conduit Transverse & Longitudinal Bracing Detail

Structural · S-SVR25

Conduit Transverse & Longitudinal Bracing Detail

Scale: 3" = 1'-0"
Units: imperial
Sheet: S-63001
Discipline: Structural

Materials

In this detail

FRONT VIEW SIDE VIEW SEE FOR ROD CONNECTION TO STRUCTURE ABOVE 1/2" Ø THREADED ROD ~ STIFFEN HANGER ROD PER DETAIL UNISTRUT P1000 CHANNEL BRACE ELECTRICAL CONDUIT UNISTRUT P1000 CHANNEL BRACE UNISTRUT P1843W HINGE, TYP PIPE CLAMP 45.00° MAX. 45.00° MAX. 6/S-63001 2/S-63001

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
