S-BD8VV — Elevator Post/Column Slip Connection - Roof Level

Structural · S-BD8VV

Elevator Post/Column Slip Connection - Roof Level

Scale: 1" = 1'-0"
Units: imperial
Sheet: S-62202
Discipline: Structural

Materials

Steel Metal (misc.)

In this detail

0'-6" RE: PLAN 0'-6" RE: PLAN B/DECK SEE PLAN L6x4x5/16 LLV EA SIDE OF HSS METAL ROOF DECK RE: PLAN ROOF STEEL BEAM, TYP RE: PLAN 1/4 1/4 TYP L2 1/2x2 1/2x1/4 KICKER PL 5/16"x6"x0'-6" @ EA ANGLE 3/16 3/16 TYP 0'-2" MIN. (1) 3/4" DIA THRU-BOLT FINGER TIGHTEN IN 2" VERTICALLY SLOTTED HOLE 3/16 3/16 TYP
