S-AX69Y — 11 Screen Wall Vertical Brace Connection

Structural · S-AX69Y

11 Screen Wall Vertical Brace Connection

Scale: 1" = 1'-0"
Units: imperial
Sheet: S-43005
Discipline: Structural

Materials

In this detail

TYP 0'-2" TYP 0'-2" TYP 0'-3" TYP 0'-3". 3/16 31 3/16 31 RE: ELEVATIONS (6) 3/4" Ø A325N BOLTS WORK POINT 16 3/16 16 3/16 6 3/16 6 3/16 (6) 3/4" Ø A325N BOLTS 1/2" THICK PL HSS BRACE, RE: ELEVATIONS FOR END BEAM CONNECTION RE: MIN 1/2". HSS BEAM RE: ELEVATIONS 6 3/16 6 3/16 TYP 1/2" 1" 1" 1" FLANGE WAS CUT FOR CLARITY 5/S-43004
