Structural · S-8WWH3

Typical Braced Frame Connection (Beam)

Scale: 1/2" = 1'-0"
Units: imperial
Sheet: S-60013
Discipline: Structural

Materials

Steel

In this detail

WHERE OCCURS TOP OF SLAB CL BRC CL BRC CL BRC CL BRC BRBF DESIGNED BY OTHERS, TYP.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
