Structural · S-7FQ38

Ledger Detail

Units: imperial
Sheet: SD3
Discipline: Structural

Materials

Metal (misc.)Steel

In this detail

10" LEDGER & TRUSS SEAT SEE (2) 3/4"Ø WELDED HEADED STUDS @ 24"OC MAX BETWEEN JOIST 10" (6) 3/4"Ø WELDED HEADED STUDS @ EACH TRUSS 1'-0" 7 - 4" 7 -
