Structural · S-2Z8DK

Dock Leveler

Units: imperial
Sheet: SD1
Discipline: Structural

Materials

Concrete Reinforced Concrete Steel

In this detail

17 DOCK LEVELER N.T.S. 8" MIN #4 @ 12"OC EA WAY #4 BARS @ 12"OC 24" #4 @ 12"OC 17 - 8" MIN L3x3x1/4" CONT W/ 1/2"Øx5" WELDED STUDS @ 24"OC

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
