P-VZDJN — Acoustical Assembly

Architectural · P-VZDJN

Acoustical Assembly

Units: imperial
Sheet: P1K
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)

In this detail

UNDERSIDE OF STRUCTURE LINE OF CEILING FINISHED FLOOR LINE A9.2.3 20 SIM POH3 : 20 GAUGE METAL STUDS AT 24" OC POH6 : 20 GAUGE METAL STUDS AT 24" OC SOUND ATTENUATION FIRE BLANKETS (SAFB) P0H3 : N/A ONE LAYER OF 5/8" TYPE X GYPSUM BOARD EACH SIDE OF METAL STUDS

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
