The pop-up rotor sits flush with the finish grade, threaded to a schedule 80 polyvinyl chloride nipple. A swing joint assembly provides flexibility between the rotor and the supply line, which connects to a schedule 40 polyvinyl chloride tee or elbow. Lateral irrigation pipe sizing and specifications follow the irrigation plans. Rotor make and model conform to the irrigation legend.
Text on the drawing
SCH. 80 PVC NIPPLE (OPTIONAL). SWING JOINT. SEE DETAIL. SCH. 40 PVC TEE OR ELBOW. PVC LATERAL IRRIGATION PIPE. (SEE IRRIGATION PLANS FOR PIPE SIZE AND TYPE). POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL) FINISH GRADE POP-UP ROTOR TO BE SET AT FINISH GRADE. (SEE IRRIGATION LEGEND FOR MAKE AND MODEL)
