G-TQNAM — Typical Floor Clearances (Ansi A117.1-2017)

General · G-TQNAM

Typical Floor Clearances (Ansi A117.1-2017)

Scale: 1/2" = 1'-0"
Units: imperial
Sheet: G004
Discipline: General

In this detail

(A) FORWARD APPROACH-ALCOVE (B) FORWARD APPROACH (C) PARALLEL APPROACH-ALCOVE (D) PARALLEL APPROACH >24" [610mm] 52" (1320mm) MIN. 30" ([762mm) MIN. 52" [1320mm] MIN. 30" [762mm] MIN. > 15" [381mm] 30" [762mm] MIN. 30" [762mm] MIN. 52" [1320mm] MIN. 52" [1320mm] MIN. 36" (915mm) MIN. 60" (1524mm) MIN. 36" (915mm) MIN. D
