G-4WAAB — Toe/Knee Clearances (Ansi A117.1-2017)

General · G-4WAAB

Toe/Knee Clearances (Ansi A117.1-2017)

Units: imperial
Sheet: G005
Discipline: General

In this detail

ELEVATION PLAN EQUIPMENT PERMITTED IN SHADED AREA 16" (405mm) MAX. 8" [192mm] MIN. 9" [229mm] MIN. 27" [686mm] MIN. TOE CLEARANCE 6" [142mm] MIN. 11" [279mm] MIN. 25" [635mm] MAX. 17" [432mm] MIN. 30" [762mm] MIN. NOTE: DRINKING FOUNTAINS TO BE PROVIDED WITH TENANT IMPROVEMENT. 17' MIN. - 25" MAX.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
