A-WPVCR — Curtain Wall Mullion Connection Detail

Architectural · A-WPVCR

Curtain Wall Mullion Connection Detail

Scale: 3" = 1'-0"
Units: imperial
Sheet: A602
Discipline: Architectural

Materials

Glass / Glazing Steel

In this detail

1 1/2" 1 1/2" 2" 1 1/2" 8" HSS 5 X 2 X 3/8 (4) 3/4" X 6" TITEN HD 1/2" X 8" X 5 1/2" STEEL CAP PLATE (4) 3/4" X 6" TITEN HD FASTEN PER MANUFACTURER'S SPECIFICATIONS ALL STEEL AND FASTENERS 2" 5" ALL STEEL AND FASTENERS PAINTED BLACK TO MATCH
