A-TMTC3 — Stair Detail @ Floor Level Landing

Architectural · A-TMTC3

Stair Detail @ Floor Level Landing

Scale: 1 1/2" = 1'-0"
Units: imperial
Discipline: Architectural

Materials

In this detail

WORK POINT 033000 - CONCRETE FILLED LANDING PLATFORM 033000 - CONCRETE FLOOR SLAB 055113 - 1 1/2" DIA STD PIPE (TYP) 051200 - STRUCTURAL STEEL 3" 1 1/2" 3" 3" 3" 4" TREAD
