A-M65MD — Ramp Guardrail/Handrail

Architectural · A-M65MD

Ramp Guardrail/Handrail

Scale: 1/2" = 1'-0"
Units: imperial
Sheet: A-60001
Discipline: Architectural

Materials

In this detail

42" MIN. EQ EQ RAMP EDGE PROTECTION RAIL; SHALL NOT PERMIT PASSAGE OF 4" SPHERE 4" RETURN HANDRAIL TO WALL OR WALKING SURFACE IF NO WALL IS PRESENT 1-1/2" DIAMETER PAINTED STEEL GUARDRAIL 1-1/2" DIAMETER PAINTED STEEL HANDRAIL 12" MIN. 12" MIN. 34" MIN. - 38" MAX. 27" MAX
