Architectural · A-F23Y2

Steel Connection @ Wall - Elevation

Scale: 3" = 1'-0"
Units: imperial
Sheet: A602
Discipline: Architectural

Materials

Metal (misc.)Steel

In this detail

8" HSS 5 X 2 X 3/8 (4) 3/4" X 6" TITEN HD 1/2" X 8" X 5 1/2" STEEL CAP PLATE 2" A602 4 SIM. 1 1/2" 1 1/2" 2" 1 1/2"
