Architectural · A-E3Z56

Accessible Ramp

Scale: 1" = 1'-0"
Units: imperial
Sheet: AD-4
Discipline: Architectural

Materials

Concrete

In this detail

18 - 4'-0" CLEAR CONCRETE RAMP SURFACE - MEDIUM BROOM FINISH 30" MAX. 4" 1" MIN. 30" - 34" 34" - 38"
