A-AE47J — Stair Detail - Typical Intermediate Landing

Architectural · A-AE47J

Stair Detail - Typical Intermediate Landing

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Discipline: Architectural

Materials

Concrete Metal (misc.)

In this detail

LEADING EDGE OF TYP STAIR TREAD 033000 CONCRETE FILL IN 055113 - METAL LANDING PLATFORM CENTERLINE OF GUARD SUPPORT 4" 3" 3" 3' - 0" HANDRAIL (TYP) 3' - 6" GUARD (TYP) 11" TREAD (TYP) 1" TYP 1 1/2"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
